5G Core Function-Based

5G Core Service-Based

LandSlide 주요 기능

Spirent사의 Landslide 장비는 3GPP 표준을 기반으로 개발된 3G/4G/5G NSA & SA Core Network 장비의 성능을 시험하거나 각 Node를 에뮬레이션합니다.

최신 5G NSA/SA 표준을 모두 지원하며 다양한 SB Node 들을 에뮬레이션하여 5G Core Network 장비와 연동 시험 지원 및 SB 노드 에뮬레이션을 제공합니다.

또한, gNB의 CU 장비를 시험하기 위한 F1인터페이스를 지원함으로써 CU 장비의 성능을 다양한 시나리오를 통해 검증하고 측정할 수 있습니다.

LandSlide Test Server 종류

  • C100-M4
    • For Massive Scale
    • 5M UEs & 100K gNBs
    • 10G SFP+ / 25G SFP28 / 40G QSFP+
    • 100G QSFP28
    • Up to 40G*4Ports
    • Up to 32 TS per Test Manager
  • vLS (Virtual)
    • Wide Range of Options
    • Small – 1000 UEs
    • Large – 100K UEs
    • xLarge – 400K UEs
    • xxLarge – 1.25M UEs
    • High Performance Virtual License
  • E10
    • OTA & Non-OTA test
    • Wi-Fi OTA Test
    • Lower performance
    • Lower Price
    • 1*2GbE interface
    • Same features with others

CU Testing

Spirent사의 Landslide 장비는 gNB 개발에 따른 CU Test 환경을 제공합니다.

* CU-Nodal 5G NSA eNB Test Configuration with Landslide 5G NSA Core

* CU-Nodal 5G SA gNB Test Configuration with Landslide 5G SA Core

  • UPF Nodal with UE/ gNB/ AMF/ SMF emulation
  • N3, N4 interface validation
  • User Plan Performance
  • E2E Service emulation & quality analysis

CUPS Testing

Spirent사의 Landslide 장비는 4G LTE/ 5G NSA CUPS 기반을 포함한 3GPP 표준을 기반으로 Core 시험을 위한 시뮬레이터 환경을 제공합니다.

AMF Testing

Spirent사의 Landslide 장비는 5G SA Core AMF 시험을 위한 시뮬레이터 환경을 제공합니다.

5G RAN and Content Emulation
High Scale 5G Device emulation
5G NR RAN emulation
Configurable N1, N2, N3 interfaces
5G AKA, 5G EAP-AKA Authentication
SUCI encryption
Multi-PDUs per UE
Native slicing
LADN access & emulation
CDN emulation
IMS emulation

SMF Testing

Spirent사의 Landslide 장비는 5G SA Core SMF 시험을 위한 시뮬레이터 환경을 제공합니다.

5G SA Core SMF Testing
UE, Multi-node NR and AMF emulation for SMF testing exposing N11 and N3 interfaces
Dual-stack PDU session support
UPF Emulator for SMF isolation testing
Service-based node emulators to complete SMF testing ecosystem

UPF Testing

Spirent사의 Landslide 장비는 5G SA Core UPF 시험을 위한 시뮬레이터 환경을 제공합니다.

UPF Nodal test case features
Multi-node 5G SA core radio access(gNB) and control plane emulation (AMF+SMF)
5G Service-nodes integrated (PCF, UDM, AUSF, …)
Multi-peer N3,N4 and N6 interface support
High throughput (Fireball support)
Content network emulation (optional)

UDM Testing

Spirent사의 Landslide 장비는 5G SA Core UPF 시험을 위한 시뮬레이터 환경을 제공합니다.

5G SA Service based nodes emulation
Multi-node 5G SA core Service Based functions (AMF+SMF+AUSF)
Subscriber management information and authentication emulation
Multi-peer N8,N10,N13 interface testing and node emulation

AUSF Testing

Spirent사의 Landslide 장비는 5G SA SB node인 AUSF 시험을 위한 시뮬레이터 환경을 제공합니다.

5G SA Service based nodes emulation
Multi-node 5G SA core Service Based functions (AMF+gNB/UE)
Subscriber authentication emulation
Multi-peer N12 and N13 interfaces testing and node emulation

PCF Testing

Spirent사의 Landslide 장비는 5G SA SB node인 AUSF 시험을 위한 시뮬레이터 환경을 제공합니다.

5G SA Service based nodes emulation
Multi-node 5G SA core Service Based functions (AMF+SMF)
Subscriber policy rules to Control Plane function emulation
Multi-peer N7 and N15 interfaces testing and node emulation

계측기 PoC 또는 소개자료가 필요하시면 이알케이솔루션㈜ / 031-388-9071로 연락주세요.
